Film Vacuum Coating & Metalizing Machine/ Coater & Metallizer (Magnetron Sputtering Type)
Products >
Film Vacuum Coating & Metalizing Machine/ Coater & Metallizer (Magnetron Sputtering Type)
Film Vacuum Coating & Metalizing Machine/ Coater & Metallizer (Magnetron Sputtering Type)
Film Vacuum Metalizing & Coating Machine( Magnetron Sputtering Type), as our newest and highly technical product, owning the top and best technical in China, the equipment owning the best performance on CPP PET BOPP PVC film and mainly used in the plastic film substrate coated functional film like solar control film, Low-E film, ITO transparent conductive film, and also for docerative film, the vehible front window film,anti-frost film, reflective film, functional layers, especially coating conductive film for electrics, which is most favorite for many customers.
Click to enlarge
Description
Film vacuum coating & metalizing machine coater/metallizer( magnetron sputtering type), we adopt China best industry technical to coating each kind material on substrate by magnetron sputtering type. mainly used for solar control film, Low-E film, ITO transparent conductive film, reflective film, functional layers, etc.Application
Film vacuum coating equipment magnetron sputtering type is mainly use front windscreen in car, train, ship, doors, windows, curtain film, anti-static and electromagnetic film, decorative film, packaging film, solar greenhouse film, electric heater film, anti-frost and fog transparent film, LCD display and electroluminescent display with transparent electrode film.Features
1. The operation is simple and convenient.2. The adhesive power is stronger.
3. The uniformity of film is superior.
4. The layer of film is delicate and flat
Parameters
| Model | JM800 | JM1350-1 | JM1800-1 | JM3000-1 |
| Maximum | 800 mm | 1350 mm | 1600 mm | 3500 mm |
| Maximum Rolling Diameter | Φ500 mm | |||
| The Dimension of Vacuum Chamber | Φ1180 × 1050 mm | Φ2000 × 1800 mm | Φ2000 × 2500 mm | Φ2200 × 3600 mm |
| Evaporation Pressure | 4 ×10-2Pa | |||
| Water Consumption(m3/h) | 20 | 35 | 40 | 50 |
| Average Power Consumption (kW) | 60 | 140 | 180 | 260 |
| Metallised Materials | PET: 25 to 150μm, CPP: 20 to 150μm, BOPP: 18 to 150μm | |||
| Vacuum System | Diffusion pump + Roots pump +Mechanical pump+ Maintaining pump | |||
| Maximum Rolling Speed | 5 m to 30 m/min | |||
| Way of Control | Manual+ Automatic/Touch Screen + PLC | |||
